Nimonic 90 Strip for Aerospace Turbine Blades Creep & Oxidation Resistant Superalloy

Nimonic 90 is a high-performance nickel-chromium-cobalt superalloy specifically engineered for the most demanding aerospace applications. As one of the premier creep-resistant alloys, it delivers exceptional high-temperature strength, oxidation resistance, and thermal fatigue properties, making it the material of choice for turbine blades and other critical hot-section components in jet engines and gas turbines.

This advanced superalloy strip combines outstanding mechanical properties with long-term structural stability at temperatures up to 920°C (1688°F), outperforming many conventional nickel-based alloys in extreme operating conditions.

Key Properties of Nimonic 90 Alloy Strip

Nimonic 90 offers an exceptional combination of properties that make it ideal for aerospace applications:

✔ Superior Creep Resistance - Maintains strength under continuous stress at high temperatures

✔ Excellent Oxidation Resistance - Forms a protective Cr₂O₃ scale at elevated temperatures

✔ High Tensile Strength - Up to 1000 MPa (145 ksi) at room temperature

✔ Outstanding Thermal Fatigue Resistance - Withstands repeated thermal cycling

✔ Age-Hardenable - Strengthened by γ' (gamma prime) precipitation hardening

✔ Good Fabricability - Can be forged, machined, and welded with proper techniques

Typical Composition (wt%):

Nickel (Ni): ~55% (base)

Chromium (Cr): 18-21% (oxidation resistance)

Cobalt (Co): 15-21% (solid solution strengthening)

Titanium (Ti): 2.0-3.0% (γ' formation)

Aluminum (Al): 1.0-2.0% (γ' formation)

Iron (Fe): ≤2.0%

Carbon (C): ≤0.13%

Primary Applications of Nimonic 90 Strip

1. Aircraft Turbine Blades (Critical Hot-Section Components)

Nimonic 90 is particularly suited for turbine blades in:

High-pressure turbine stages of jet engines

Industrial gas turbines for power generation

Military aircraft engines requiring extreme reliability

Performance Advantages:

Maintains strength at 850-920°C (1562-1688°F)

Resists creep deformation better than Inconel 718

Withstands thermal shock during rapid engine startups/shutdowns

2. Turbine Disks and Shafts

Used in rotor assemblies where high centrifugal forces occur

Provides excellent fatigue resistance under cyclic loading

3. Exhaust System Components

Afterburner parts in military jets

Nozzle guide vanes requiring oxidation resistance

4. High-Temperature Fasteners

Turbine casing bolts that must maintain clamp load at temperature

Combustor assembly hardware

Why Aerospace Manufacturers Choose Nimonic 90 Strip

✔ Unmatched Creep Resistance for Turbine Applications

Outperforms common alloys like Inconel 718 and Waspaloy in long-term creep strength at temperatures above 750°C (1382°F)

✔ Superior Oxidation Resistance

Forms a stable, self-healing oxide layer that prevents degradation in high-velocity combustion gases

✔ Proven Reliability in Critical Components

Has been used in Rolls-Royce, GE, and Pratt & Whitney engines for decades

✔ Optimized Balance of Properties

Offers better strength-to-weight ratio than many cobalt-based superalloys

✔ Cost-Effective for Performance Level

More economical than single-crystal superalloys while delivering 85-90% of their performance

Material Specifications & Availability

Available Forms:

Precision cold-rolled strips (0.1-3.0mm thickness)

Hot-rolled plates and bars

Custom forgings for turbine components

Common Standards:

AMS 5798 (Aerospace Material Specification)

BS HR 5 (British Standard)

DIN 2.4632 (European Standard)

UNS N07090

Heat Treatment Options:

Solution annealing (1080°C ±10°C)

Aging treatment (700-800°C for 16 hours)

FAQ:

What is the brand name of the High Temperature Alloy product?

Answer: The brand name of the product is DLX

What is the model number of the high temperature alloy product?

Answer: The model number of the product is High Temperature Alloy.

Where is the product made?

Answer: The product is made in China JiangSu.

What is the minimum order quantity for the product?

Answer: The minimum order quantity for the product is

What is the expected delivery time for the product?

Answer: The expected delivery time for the product is 5-7 days.
