Incoloy Rod Incoloy 925 Alloy Bar for High Temperature Pressure Vessels and High-Pressure Systems

‌1. Product Information‌

‌Product Name‌: Incoloy 925 Bar (Sulfide Stress Corrosion Resistant Grade)
‌Material Type‌: Nickel-Iron-Chromium-Molybdenum-Copper Alloy (Age-Hardenable)
‌Standards‌: ASTM B425, NACE MR-0175/ISO 15156, UNS N09925, API 6ACRA
‌Forms Available‌: Hot-rolled bars, cold-drawn precision bars, and solution-treated blanks.
‌Diameter Range‌: 12 mm to 350 mm (custom sizes up to 500 mm).
‌Surface Finish‌: Peeled, ground (Ra ≤ 0.8 μm), or shot-peened.
‌Heat Treatment‌:

• Solution Annealing: 885-925°C (1625-1700°F) + water quench

• Aging: 620-650°C (1150-1200°F) for 16 hours

‌Mechanical Properties‌:

• Yield Strength: 760-965 MPa (110-140 ksi)

• Hardness: 28-35 HRC

Certifications‌: NORSOK M-630, DNVGL-RP-F112, ISO 13680 for OCTG.

‌2. Characteristics‌

Incoloy 925 bars are engineered for extreme H₂S and chloride environments:

• ‌Sulfide Stress Cracking (SSC) Resistance‌: Threshold stress >90% AYS in NACE TM0177 Solution A.

• ‌Chloride Pitting Resistance‌: Critical pitting temperature (CPT) >100°C in 25% NaCl per ASTM G48.

• ‌High-Temperature Strength‌: Retains 85% yield strength at 400°C (750°F).

• ‌Hydrogen Embrittlement Immunity‌: No cracking after 720-hour testing in H₂S-saturated brine.

• ‌Aging Response‌: γ' (Ni₃Ti) precipitation increases hardness by 15 HRC post-treatment.

• ‌Fatigue Performance‌: Endurance limit of 450 MPa (65 ksi) at 10⁷ cycles (R=-1).

‌3. Technology‌

‌Manufacturing Process‌:

• ‌Triple Melt Process (VIM + ESR + VAR)‌: Achieves S < 0.002%, O₂ < 20 ppm.

• ‌Controlled Forging‌: At 950-1100°C with 4:1 reduction ratio to refine grain structure.

• ‌Precision Aging‌: Multi-stage aging at 595°C + 650°C to optimize γ' precipitate distribution.
  ‌Quality Control‌:

• Automated ultrasonic testing (AUT) for internal defects (sensitivity 0.5 mm).

• Slow strain rate testing (SSRT) per NACE TM0198.

• Hydrogen charging simulation with 1 atm H₂ at 200°C for 48 hours.

‌4. Theory‌

The alloy’s sour service performance originates from:

• ‌Molybdenum-Titanium Synergy‌: Mo provides solid solution strengthening, while Ti forms γ' precipitates (Ni₃Ti) for age hardening.

• ‌Copper-Enhanced Passivation‌: Cu promotes Cr₂O₃-MoO₃ oxide layer regeneration in H₂S environments.

• ‌Nickel Matrix Dominance‌: High Ni (>42%) stabilizes austenitic structure against hydrogen ingress.

• ‌Carbon Control‌: Ultra-low C (<0.03%) prevents Cr-carbide formation at grain boundaries.

• ‌Dislocation-Precipitate Interaction‌: γ' particles (10-50 nm) obstruct dislocation movement, enhancing yield strength.

‌5. Application‌

Incoloy 925 bars are critical in aggressive hydrocarbon extraction:

• ‌Downhole Tools‌:

• Subsurface safety valve components, packer mandrels, and ESP shafts.

• ‌Well Completion‌:

• H₂S-resistant hangers, Christmas tree bolts, and blowout preventer (BOP) parts.

• ‌Pipeline Systems‌:

• Clad weld overlay on carbon steel pipes for sour gas transmission.

• ‌Refining‌:

• Hydrotreater reactor internals and sour water stripper column trays.
