Incoloy 800HT High Temperature Alloy Wire for Turbine Blades and Aerospace Engine Parts

1. Product Information‌

‌Product Name‌: Incoloy 800HT Wire
‌Material Type‌: Nickel-Iron-Chromium Superalloy (High-Temperature Variant)
‌Standards‌: ASTM B407, ASTM B408, AMS 5766, UNS N08811, DIN 1.4876
‌Forms Available‌: Round wire, flat wire, spooled wire, and custom-drawn profiles.
‌Diameter Range‌: 0.2 mm to 12.0 mm (customizable upon request).
‌Surface Finish‌: Bright annealed, pickled, or electro-polished.
‌Operating Temperature‌: Continuous service: Up to 870°C (1600°F), Short-term exposure: Up to 1100°C (2012°F)

‌Certifications‌: Compliant with NACE MR-0175 for sour gas resistance and ASME Boiler & Pressure Vessel Code.

‌2. Characteristics‌

Incoloy 800HT wire is a high-performance variant of Incoloy 800, designed for extreme temperature and stress conditions:

• ‌Superior Creep Resistance‌: High carbon content (0.06-0.10%) and controlled Al/Ti ratio enhance time-dependent deformation resistance at 600–900°C.

• ‌Oxidation & Carburization Resistance‌: Forms a dense Cr₂O₃-Al₂O₃ dual-layer oxide, protecting against scaling and carbon ingress in hydrocarbon-rich atmospheres.

• ‌Phase Stability‌: Retains austenitic structure without sigma-phase embrittlement even after prolonged thermal exposure.

• ‌Mechanical Strength‌: Tensile strength of 550-750 MPa at 800°C, with creep rupture life exceeding 10,000 hours at 700°C/100 MPa.

• ‌Thermal Fatigue Resistance‌: Low coefficient of thermal expansion (15.0 μm/m·°C at 20–600°C) minimizes stress during cyclic heating.

• ‌Fabrication Adaptability‌: Compatible with TIG, laser, and electron beam welding; cold-forming possible with intermediate annealing.

‌3. Technology‌

‌Manufacturing Process‌:

• ‌Vacuum Induction Melting (VIM)‌: Ensures precise control over carbon and impurity levels (S < 0.015%, P < 0.02%).

• ‌Thermomechanical Processing‌: Hot-rolled billets are cold-drawn with multi-pass dies to achieve ±0.015 mm dimensional accuracy.

• ‌Heat Treatment‌:

• Solution annealing at 1120-1170°C (2050-2140°F) to dissolve secondary phases.

• Rapid argon quenching to lock carbon in solid solution.

• ‌Surface Engineering‌: Electropolishing reduces surface roughness (Ra < 0.4 μm) for enhanced corrosion resistance.

‌Quality Control‌:

• Glow discharge spectrometry (GDS) for trace element analysis.

• Creep rupture testing per ASTM E139 at 700°C/100 MPa.

• Microstructural examination via SEM/EDS to verify carbide distribution.

‌4. Theory‌

The alloy’s exceptional high-temperature performance is rooted in its metallurgical design:

• ‌Solid Solution Strengthening‌: Nickel stabilizes the austenitic matrix, while chromium enhances oxidation resistance.

• ‌Carbon Optimization‌: Controlled carbon content promotes intragranular M₂₃C₆ carbides, which pin dislocations and inhibit creep deformation.

• ‌Aluminum-Titanium Synergy‌: Al and Ti combine with carbon to form fine (Ti,Al)C precipitates, strengthening grain boundaries against creep cavitation.

• ‌Thermal Stability‌: The Ni-Fe-Cr ternary system suppresses harmful phase transformations (e.g., sigma, chi phases) even after 10,000 hours at 800°C.

• ‌Self-Healing Oxide Layer‌: Chromium and aluminum oxides regenerate dynamically under thermal cycling, maintaining barrier integrity in oxidizing/carburizing environments.

‌5. Application‌

Incoloy 800HT wire is critical in industries requiring prolonged exposure to extreme heat and mechanical stress:

• ‌Petrochemical‌:

• Ethylene cracking furnace tubes, pyrolysis coil supports, and hydrogen reformer internals.

• Wire mesh for sulfur recovery unit (SRU) components.

• ‌Power Generation‌:

• Gas turbine combustion liners, exhaust ducting springs, and superheater tube hangers.

• Nuclear reactor control rod drive mechanisms.

• ‌Heat Treatment Industry‌:

• Fixtures for carburizing furnaces, annealing trays, and quenching basket assemblies.

• ‌Aerospace‌:

• Afterburner flame holders, turbine seal rings, and rocket engine injector elements.

• ‌Chemical Processing‌:

• Catalyst carrier grids in nitric acid plants and syngas reactors.
