High Performance Incoloy 800HT Alloy Bar for Gas Turbine Blades and Aerospace Parts

1. Product Information‌

‌Product Name‌: Incoloy 800HT Bar (High-Temperature Creep-Resistant Grade)
‌Material Type‌: Nickel-Iron-Chromium Superalloy (Austenitic, High-Carbon Variant)
‌Standards‌: ASTM B408, ASME SB408, UNS N08811, EN 10095
‌Forms Available‌: Hot-forged bars, extruded bars, and precision-ground bars.
‌Diameter Range‌: 15 mm to 400 mm (customizable up to 600 mm for forged applications).
‌Surface Finish‌: Pickled, blasted, or electropolished (Ra ≤ 0.4 μm).

‌Operating Temperature‌:

• Continuous service: Up to 950°C (1742°F)

• Short-term exposure: 1150°C (2102°F) for <50 hours

Certifications‌: ASME Section III (Nuclear), TÜV Rheinland PED 2014/68/EU, ISO 15156 for sour service.

‌2. Characteristics‌

Incoloy 800HT bars are engineered for extreme creep resistance and oxidation stability in ultra-high-temperature environments:

• ‌Enhanced Creep Strength‌: 100,000-hour rupture life of 20 MPa at 850°C, 30% superior to standard 800H.

• ‌Oxidation Resistance‌: Dual-layer Al₂O₃-Cr₂O₃ oxide scale formation with oxidation rate <0.08 g/m²·h at 950°C.

• ‌Carburization Resistance‌: Carbon penetration limited to 0.3 mm after 25,000 hours in gas atmospheres (ac₃ <0.25).

• ‌Thermal Fatigue Resistance‌: Thermal expansion coefficient of 14.2 μm/m·°C (20–800°C) minimizes cyclic stress.

• ‌Phase Stability‌: No sigma-phase formation after 20,000 hours at 900°C, maintaining 20% elongation.

• ‌Weldability‌: Compatible with laser and electron beam welding (AWS A5.14 ERNiCr-3 filler).

‌3. Technology‌

‌Manufacturing Process‌:

• ‌Triple Melt Technology (VIM + ESR + VAR)‌: Reduces impurities (S < 0.002%, O₂ < 15 ppm).

• ‌Isothermal Forging‌: At 1100–1200°C under 250 MPa to achieve ASTM grain size 2-4.

• ‌Heat Treatment‌:

• Solution annealing at 1200°C (2192°F) with helium quenching.

• Stabilization annealing at 900°C (1652°F) for 5 hours to homogenize M₂₃C₆ carbides.
  ‌Quality Control‌:

• Ultrasonic testing (UT) per ASTM A388 for defects >0.5 mm.

• Creep rupture testing per ASTM E139 (1000-hour tests at 850°C).

• Electron channeling contrast imaging (ECCI) for dislocation density analysis.

‌4. Theory‌

The alloy’s performance is anchored in advanced metallurgical principles:

• ‌Carbon-Titanium Synergy‌: Controlled C and Ti levels promote intragranular (Ti,Mo)C carbides that inhibit dislocation climb at >800°C.

• ‌Aluminum Redistribution‌: Al diffuses to grain boundaries, enhancing oxide layer adhesion under thermal cycling.

• ‌Nickel Matrix Dominance‌: High Ni content prevents σ-phase formation while maintaining austenitic ductility.

• ‌Dynamic Recovery‌: Hot working induces polygonization of dislocations, increasing creep ductility by 25%.

‌5. Application‌

Incoloy 800HT bars are critical in next-generation energy systems:

• ‌Power Generation‌:

• Ultra-supercritical (USC) boiler tube hangers (steam conditions: 620°C/300 bar).

• Gas turbine combustor transition ducts operating at 900°C.

• ‌Hydrogen Production‌:

• Steam methane reformer (SMR) outlet headers in blue hydrogen plants.

• High-temperature electrolyzer (SOEC) interconnects for green hydrogen.

• ‌Waste-to-Energy‌:

• Grate bars in municipal waste incinerators (850°C, HCl-rich flue gas).

• ‌Cryogenic Systems‌:

• Support struts for liquid natural gas (LNG) storage tanks (-162°C to 200°C thermal cycling).
