GH3625 (Inconel 625 Equivalent) Strip Offshore & Chemical Processing Corrosion Resistant

GH3625 is a nickel-chromium-molybdenum superalloy that serves as the Chinese equivalent to Inconel 625, offering exceptional corrosion resistance, high strength, and outstanding fabrication characteristics. This versatile alloy strip is particularly valued in offshore oil & gas, chemical processing, and marine engineering where resistance to pitting, crevice corrosion, and stress-corrosion cracking is critical.

Engineered to withstand some of the most aggressive environments, GH3625 maintains excellent mechanical properties from cryogenic temperatures up to 980°C (1800°F), making it a premium choice for demanding industrial applications.

Key Properties of GH3625 Alloy Strip

GH3625 delivers an optimal combination of properties for corrosive environments:

✔ Superior Corrosion Resistance

Outstanding resistance to pitting, crevice corrosion, and chloride-ion stress corrosion cracking

Performs well in acidic, alkaline, and saline environments

✔ Excellent Mechanical Strength

Maintains high tensile strength (≥830 MPa) and toughness across wide temperature ranges

Good fatigue resistance for dynamic loading applications

✔ Exceptional Fabricability

Excellent weldability without post-weld heat treatment

Good formability and machinability compared to other superalloys

✔ High-Temperature Stability

Retains strength and resists oxidation up to 980°C (1800°F)

Resists carburization and nitridation in harsh processing environments

✔ Cost-Effective Alternative

Provides equivalent performance to Inconel 625 at more competitive pricing

Typical Composition (wt%):

Nickel (Ni): ≥58% (base)

Chromium (Cr): 20-23% (corrosion resistance)

Molybdenum (Mo): 8.0-10.0% (pitting resistance)

Niobium (Nb): 3.15-4.15% (strengthening)

Iron (Fe): ≤5.0%

Carbon (C): ≤0.10%

Primary Applications of GH3625 Strip

1. Offshore Oil & Gas Equipment

GH3625 is extensively used in:

Subsea components (risers, umbilicals, flowlines)

Seawater handling systems (pump shafts, valve trim)

Platform splash zone components

Performance Advantages:

Resists chloride-induced stress corrosion cracking in seawater

Withstands H₂S-containing environments in sour service

Provides long-term reliability in subsea applications

2. Chemical Processing Equipment

Reactor vessels and heat exchangers

Distillation columns for aggressive chemicals

Piping systems handling acids and chlorides

Key Benefits:

Excellent resistance to:

Sulfuric, phosphoric, and hydrochloric acids

Chlorine and fluorine compounds

Maintains integrity in polluted and industrial atmospheres

3. Pollution Control Systems

Flue gas desulfurization (FGD) components

Scrubbers and exhaust systems

Waste treatment equipment

4. Aerospace & Marine Components

Aircraft ducting systems

Marine propeller shafts and fasteners

Nuclear reactor components

Why Engineers Specify GH3625 Strip

✔ Unmatched Corrosion Resistance

Outperforms stainless steels (e.g., 316L, 254SMO) in severe corrosive environments

✔ Proven Reliability in Critical Applications

Trusted in:

Deepwater oil production

Chemical processing plants

Marine engineering projects

✔ Excellent Fabrication Characteristics

Can be welded using common techniques (GTAW, GMAW, SMAW)

Good cold forming properties

✔ Cost-Effective Superalloy Solution

Provides Inconel 625 performance at more competitive pricing

✔ Wide Temperature Range Capability

Performs reliably from cryogenic to 980°C (1800°F) service

Material Specifications & Availability

Available Forms:

Cold-rolled strips (0.1-6.0mm thickness)

Hot-rolled plates (6-50mm thickness)

Seamless tubes and pipes

Common Standards:

GB/T 15007 (Chinese standard)

Equivalent to: Inconel 625 (UNS N06625), DIN 2.4856

Typical Mechanical Properties:

Tensile Strength: ≥830 MPa

Yield Strength: ≥415 MPa

Elongation: ≥30%

Heat Treatment:

Annealing: 925-1040°C followed by rapid cooling

FAQ:

What is the brand name of the High Temperature Alloy product?

Answer: The brand name of the product is DLX

What is the model number of the high temperature alloy product?

Answer: The model number of the product is High Temperature Alloy.

Where is the product made?

Answer: The product is made in China JiangSu.

What is the minimum order quantity for the product?

Answer: The minimum order quantity for the product is

What is the expected delivery time for the product?

Answer: The expected delivery time for the product is 5-7 days.
